CWT-I003A Car Power Inverter

Description
Unlike CWT-I001, CWT-I003A power inverter has DC 24V input voltage. Compared with that of CWT-I003, the rated and peak output power is 300W and 600W. The output waveform is modified sine wave that is characterized by low noise. Its over-voltage cut-off output is more than 31V and under-voltage less than 20V. Moreover, CWT-I003A is much heavier (0.67 kg) and longer (145 mm) than CWT-I003. The minimum order quantity of this power inverter is 30 pieces. With high quality and favorable price, it is now widely sold across the USA and Europe.

Notices
1. Power inverter with DC 24V input voltage should be kept at cool and dry place away from direct sunlight and water.
2. Users are suggested to keep it from explosive and flammable things.
3. It is not allowed to put anything on it.
4. The interval time between two starting should not be less than five seconds.

Parameters of Power Inverters with DC 24V Input Voltage

Input (V)	DC 24V (22-30)
Output (V)	AC220V ± 5%
Rated Output Power (W)	300
Peak Output Power (W)	600
Output Frequency (Hz)	50/60 ± 4
USB Output Voltage (V)	5V 1A Max
Output Waveform	Modified Sine Wave
Efficiency	≥ 87%
Under Voltage Protection (V)	21-22
Under-Voltage Cut-off Output (V)	≤ 20
Over-Voltage Cut-off Output (V)	≥ 31
Socket	Universal Socket (Generally used)
Overloading Protection (W)	≥ 360
Over-Temperature Protection	≥ 60°
Short Circuit Protection	Yes
Dimension (mm)	145 × 89 × 49
Packaging Mode	Blister
Weight per Unit (Including Package) (Kg)	0.67
Net Weight/Gross Weight (Kg)	20/21
Carton Dimension (cm)	51 × 39 × 28
Set Per Carton	30
Warranty Period	12 months
Minimum Order Quantity	30PCS
